Upholding a time-tested, race-bred ethos that says nothing should hold a rider back from the sheer joy of untethered speed. Built off one of the most winning race platform in EWS history, the sb160 is pure race machinery. Honed for more. Be fastest.
- 160MM FRAME TRAVEL
- 170MM FORK TRAVEL
- 17% LEVERAGE RATE
- 29" WHEEL SIZE
- 64° HEAD TUBE ANGLE
- 77.5° EFF. SEAT ANGLE
FROM LEGACY TO DYNASTY
The Yeti/Fox Factory Team won 51 EWS stages, 12 EWS races, and 1 national series championships aboard the SB150. The SB160 builds momentum on this legacy of excellence. Honed. Refined. Even effing faster.
THE NEW SILHOUETTE OF SPEED.
The refined main frame and swingarm silhouette is more than just striking good looks — it’s an engineering approach that packages Switch Infinity and shock linkage in a tighter, more efficient frame with added impact clearance. Holistic frame chassis stiffness has increased, along with frame ground clearance.
UNPARALLELED FEEL.
FOR ALL RIDERS.
Every rider deserves a frame feel that’s tuned for them, regardless of frame size. Over the course of hundreds of virtual simulation comparisons and back-to-back carbon prototype testing, we’ve refined our carbon layups to deliver consistent torsional stiffness and flex profiles across all frame sizes. The feel is precise yet compliant while structurally balancing lightweight and durability.
Cable Management.
Internally routed cable tubes with secure closures at entry and exit points eliminate rattles and cable rub. Whether running a mechanical drivetrain and dropper or a wireless setup, cable management is intuitively easy and quiet.
Threaded BB.
Threaded aluminum bottom bracket shell with integrated ISCG-05 tabs. This critical drivetrain interface is now more durable, cleaner, and easier to service.
Universally Ready.
If a hanger bending crash occurs, the new Yeti models use the Universal Derailleur Hanger (UDH) interface — the industry standard mount for a rear derailleur. The UDH is available in nearly any bike shop, Yeti dealer or not.
HIGHLIGHTS
- Fox Factory 38 & Fox Float X2 Shock
- Fox Transfer dropper post
- Custom DT Swiss EX1700 wheels
- 4 piston CODE brakes
- ODI Elite Pro grips
- 200mm front and rear rotors
- Maxxis Assegai 2.5 EXO+ & Minion DHR 2.4 DD casing
- Downhill tested and used by the Yeti Fox Factory team
FRAME HIGHLIGHTS
- Switch Infinity assembly on T-Series
- Threaded bottom bracket
- High-clearance downtube
- Dual-density downtube protection
- Universal Derailleur Hanger (UDH)
- Secure, fully enclosed internal cable management
- Compatible with long dropper posts
- 100% standard sealed Enduro Max bearings
- Floating collet axle pivot design
- Compact-wishbone shock extender
- Downhill tested
- Yeti/Fox Factory team approved
- Boost spacing
- Sizes S-XXL
SPECIFICATION
C/Series carbon fibre frame, Switch Infinity suspension technology, threaded bottom bracket, fully enclosed internal cable routing, 148mm x 12mm BOOST dropouts, sealed Enduro Max pivot bearings, integrated derailleur hanger, and axle.
| FORK |
FOX FACTORY 38 GRIP X2 / 170MM |
| SHOCK |
FOX FACTORY FLOAT X2 |
| TYRE (F) |
MAXXIS ASSEGAI 2.5 EXO+ |
| TYRE (R) |
MAXXIS MINION DHR II 2.4 DD |
| ROTOR (F) |
SRAM CENTERLINE 200 |
| ROTOR (R) |
SRAM CENTERLINE 200 |
| HEADSET |
CANE CREEK 40 INTEGRATED |
| WHEELSET |
DT SWISS E1900 30MM |
| BB |
SRAM DUB BSA 73 |
| GRIPS |
ODI ELITE PRO |
| BAR |
BURGTEC RIDE WIDE ALLOY ENDURO 35X800MM 30MM RISE |
| STEM |
BURGTEC ENDURO MK3 35X50MM |
| CRANK |
SRAM GX EAGLE 30T 170MM |
| BASH GUARD |
MRP AMG SL BASH GUIDE |
| SEAT |
SILVERADO CUSTOM |
| BRAKES |
SRAM CODE R |
| DERAILLEUR |
SRAM GX EAGLE |
| CASSETTE |
SRAM GX EAGLE 1275 10-52 |
| CHAIN |
SRAM GX EAGLE |
| SHIFTER |
SRAM GX EAGLE |
| SEATPOST |
ONEUP DROPPER POST 31.6MM / SM: 150MM, MD: 180MM, LG-XXL: 210MM |
Please note: Specifications are subject to change without notice.
