| Frame |
CF3 III - carbon; Boost axle standard, BSA BB standard, Max. tyre size 29" x 2.4"
|
| Fork |
RockShox Judy Gold; Air; 120mm travel; Tapered; Remote lockout; 51 mm fork offset
|
| Shifters |
Shimano Deore M6100 and JD-FL dropout lever
|
| Rear Derailleur |
Shimano XT; SGS |
| Bottom Bracket |
Shimano BB-MT-501; 24mm |
| Chain |
KMC X12
|
| Chainset |
Shimano Deore MT512; 32 tooth chainset with 170mm (S), 175mm M and above |
| Cassette |
Shimano Deore M6100; 10-51 teeth; 12 speed |
| Brake Lever |
Shimano SLX
|
| Front Brake |
Shimano SLX M7100; 2 piston hydraulic disc brake with Shimano RT-54 180mm rotor |
| Rear Brake |
Shimano SLX M7100; 2 piston hydraulic disc brake with Shimano RT-54 160mm rotor |
| Grip |
Merida Expert EC
|
| Handlebar |
Merida Expert CC; aluminium; 760mm wide; flat |
| Stem |
Merida Team CC III; aluminium; 31.8mm diameter; -6 degree rise; length: 60mm (S/M/L); 70mm (XL); incl. Merida Smart Mount - Garmin Carrier + Garmin insert *2 + GoPro/Light Mount |
| Headset |
Acros ICR Merida integrated neck; Upper and lower IPS sealing |
| Pedal |
Not included |
| Saddle |
Merida Expert SL; V-mount; incl. Merida minitool
|
| Seatpost |
Merida Team TR SL; 30.9mm diameter; in-line; S/M: 150mm seat post travel (S/M), 170mm seat post travel (L/XL/XXL) |
| Wheel Size |
29 |
| Rims |
Merida Expert CC II; 25mm inner rim width; aluminium; Tubeless ready (tubeless tape and valves not included) |
| Spokes |
Double Butted Black stainless |
| Front Hub |
Shimano HB-TC500-B; 100 x 15mm; 32 Spokes; Centerlock |
| Rear Hub |
Shimano TC500-MS-B; 148 x 12mm; 32 Spokes; Centerlock with Merida Expert TR axle; including removeable lever, 6/4mm allen key |
| Front Tyre |
Maxxis Rekon; 29 x 2.4" WT; tubeless ready; 3C EXO |
| Rear Tyre |
Maxxis Rekon Race; 29 x 2.4" WT; tubeless ready; 3C MaxxTerra EXO |
