Ride roads, gravel or dirt with this versatile aluminum all-rounder. A composite fork gives it a smooth ride, and a flip chip lets you adjust wheelbase and tire clearance.

Confident handling

Frame is designed with endurance positioning and shorter chainstays for precise handling, agility and control. A longer reach, shorter stem and lower bottom bracket drop improves stability on rugged terrain.

Tuned compliance

Dropped seatstays with thin tubing absorb road shocks and vibrations. The D-Fuse handlebar and seatpost work as a system to add compliance without sacrificing stiffness while cornering, sprinting or climbing.

Adaptable to the terrain

A flip chip on the rear dropout adjusts the wheelbase: short for quicker handling and acceleration, or long for improved stability at speed. The long setting allows for larger diameter tyres up to 53mm. You can choose the included D-Fuse seatpost for maximum compliance, or switch to a 30.9mm round or dropper post.

365 day returns	Add to Wishlist
Seen it cheaper? Price Match*

365 day returns

Add to Wishlist

Seen it cheaper? Price Match*

Ride roads, gravel or dirt with this versatile aluminum all-rounder. A composite fork gives it a smooth ride, and a flip chip lets you adjust wheelbase and tire clearance.

Confident handling

Tuned compliance

Adaptable to the terrain

ALUXX Aluminium Technology

This Performance level frame material features 6061 alloy with single-butted tubes to produce strong, lightweight framesets for a variety of different bikes and riding styles.

D-Fuse Technology

The D-Fuse seatpost and handlebar were designed to function as a system, absorbing road shocks and vibrations so you can ride farther, faster.

Flip Chip - Dropout

Allows riders to quickly adjust the geometry and rear-wheel tire clearance with eccentric, offset two-position hardware in the rear wheel dropouts.

OverDrive

Giant’s original oversized fork steerer tube technology. Designed to provide precise front-end steering performance, the system’s oversized headset bearings (1 1/4” lower and 1 1/8” upper for road, 1 1/2” lower and 1 1/8” upper for mountain) and tapered steerer tube work in conjunction to provide optimal steering stiffness.

Tubeless System

Fewer flat tires. Greater traction. Less rolling resistance and a smoother, faster ride. Giant’s Tubeless System makes it easier than ever to experience all these benefits.

Colours	Asphalt Green, Storm Cloud
Frame	ALUXX-grade aluminium, 12x142mm thru-axle, disc, flip chip dropout
Fork	Advanced-grade composite, full-composite OverDrive steerer, 12mm thru-axle, disc
Handlebar	Giant Contact XR Ergo-Control, 31.8mm
Stem	Giant Sport, 8-degree
Seatpost	Giant D-Fuse, alloy, 14mm offset
Saddle	Giant Approach
Pedals	PEDALS NOT SUPPLIED
Shifters	Shimano Sora, 2x9
Front Derailleur	Shimano Sora, 2x9
Rear Derailleur	Shimano Sora, long cage
Brakes	Tektro MD-C550 mechanical, Giant MPH rotors [F]160mm, [R]160mm
Brake Levers	Shimano Sora
Cassette	Shimano HG400, 11x34
Chain	KMC X9 with Missing Link
Crankset	FSA Vero Pro, 32/48
Bottom Bracket	Cartridge
Rims	Giant S-X2 Disc wheelset, alloy, 25mm inner rim width
Hubs	Giant alloy, 12mm thru-axle
Spokes	Stainless
Tyres	Giant CrossCut AT 2, 700x38c, tubeless
Extras	Factory tubeless set up
Max Tyre Clearance	53mm max tyre size in "long" flip chip position, 45mm max tyre size in "short" flip chip position
Max Chainring Size	SRAM Wide 2x 43-30, 1x 46T. SRAM Road 2x 52-39, 1x 52T. Shimano Road 2x 52-36. GRX 2x 48-31, 1x 42T
Weight	The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight but in reality weight can vary based on size finish hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
